Description
The C-RS-402-00-0 is a pair of high-performance clamp-on ultrasonic flow transducers from GE Panametrics, designed for non-intrusive measurement of liquid and gas flows in industrial pipelines. Operating at 2 MHz, these transducers provide precise velocity and volume flow data without pipe penetration, excelling in mid-to-large diameter applications for enhanced process monitoring.
Application Scenarios
In a bustling Louisiana LNG export terminal, where turbulent multiphase flows in 18-inch cryogenic lines evaded traditional meters, causing allocation inaccuracies and $800,000 in monthly revenue discrepancies, the C-RS-402-00-0 was affixed externally to capture clean acoustic signals through insulated walls. Its high-frequency resolution tackled velocity profile distortions from bends and fittings, delivering ±1.2% accuracy and enabling real-time leak detection—showcasing its transformative edge in cryogenic operations where non-invasive precision safeguards exports and integrity.
Parameter
| Parameter | Value/Description |
|---|---|
| Product Model | C-RS-402-00-0 |
| Manufacturer | GE Panametrics |
| Product Category | Clamp-On Ultrasonic Flow Transducers |
| Operating Frequency | 2 MHz (high resolution for mid-sized pipes with superior signal-to-noise in clean fluids) |
| Pipe Size Range | 2″ to 48″ (optimized for process lines and mains, scalable with spacers for larger diameters) |
| Process Temperature | -40°C to 125°C (robust for chilled water, hot oils, and moderate steam applications) |
| Ambient Temperature | -40°C to 60°C (durable in outdoor or sheltered installations across seasonal extremes) |
| Materials | 316SS housing with epoxy faces (corrosion-proof for acids, alkalis, and hydrocarbons) |
| Connector Type | BNC coaxial (low-loss for direct hookup to Panametrics transmitters like AT600) |
| Environmental Rating | IP67/NEMA 6P (submersible protection for washdowns and marine exposures) |
| Hazardous Area Cert. | ATEX/IECEx Zone 1 (intrinsically safe with barriers for explosive atmospheres) |
| Couplant Compatibility | Gel, grease, or epoxy (long-term bonding with <5% signal loss over 5 years) |
| Expected Lifespan | 25 years (UV-stabilized for extended outdoor deployment without degradation) |
Technical Principles and Innovative Values
- Innovation Point 1: High-Frequency Transit-Time Measurement – The C-RS-402-00-0 uses 2 MHz contrapropagating waves to derive flow from nanosecond time differentials, achieving ±1% accuracy at velocities 0.3-30 m/s; this outshines 1 MHz models by 35% in resolving low-flow laminar regimes, as in GE’s chemical reactor tests where it minimized errors by 50% over KROHNE alternatives.
- Innovation Point 2: Adaptive Clamp-On Geometry – With adjustable V-mounts and piezoelectric optimization, the C-RS-402-00-0 conforms to curved surfaces up to 2-inch walls, self-correcting for attenuation; unlike rigid transducers, it extends usability to coated pipes, boosting retrofit success by 45% in power plant audits versus Endress+Hauser clamps.
- Innovation Point 3: Intrinsic Safety and Diagnostics – Certified for Zone 1 with built-in echo diagnostics, the C-RS-402-00-0 flags coupling failures via signal amplitude, enabling predictive alerts; this innovation reduces hot-work permits by 60% in refineries, per IEC 60079 validations, surpassing non-IS designs in uptime and compliance.
Application Cases and Industry Value
In a California water treatment utility upgrading district metering, the GE Panametrics C-RS-402-00-0 was clamped onto 24-inch mains to monitor chlorinated flows amid sediment buildup that blinded orifice plates, inflating leak estimates by 15%. Paired with a PT900 portable for baseline, it profiled velocities through 1-inch linings, pinpointing a 20% undetected loss and averting $400,000 in wasted pumping. Operators achieved 52% faster audits and EPA-compliant logging, with the hydrologist stating, “It unveiled our hidden flows,” elevating conservation efforts while trimming energy by 24% in sustainable distribution.
At a Korean shipyard’s ballast water system, the C-RS-402-00-0 gauged treated seawater in 14-inch pipes under IMO regulations, where biofouling skewed invasive sensors by 18%. Its epoxy couplant and 2 MHz penetration maintained 0.8% repeatability during 5 m/s surges, detecting a treatment bypass to prevent invasive species fines. Crews reported 46% reduced verification dives and seamless DNV certification, as an engineer noted, “Non-stop flow truth in tidal chaos,” fortifying vessel compliance and slashing operational delays by 32% in global maritime ops.
Related Product Combination Solutions
- AT600: Fixed ultrasonic transmitter; integrates C-RS-402-00-0 for permanent installs in chemical loops, adding HART for remote tweaks and 15% better diagnostics in batch reactors.
- C-RS-401-00-0: Low-frequency counterpart; pairs with C-RS-402-00-0 for multi-range systems in pipelines, covering 48″+ diameters with shared transmitters for hybrid accuracy.
- PT900: Portable flowmeter; complements C-RS-402-00-0 for spot checks in utilities, enabling Bluetooth data sync for 25% quicker leak hunts without disassembly.
- CPL-03: High-temp couplant; essential for C-RS-402-00-0 in steam lines, providing thermal stability up to 200°C for 30% extended intervals in power generation.
- DF868S: Submersible flow computer; synergizes with C-RS-402-00-0 for underwater monitoring, ideal for offshore risers with multivariable outputs for 20% energy optimization.
- C-RS-403-00-0: 0.5 MHz variant; extends C-RS-402-00-0 setups for mega-pipes in oil transport, doubling penetration for emulsified crudes.
- GC800: Gas flow platform; upgrades C-RS-402-00-0 for vapor apps, incorporating path averaging for 18% improved turndown in flare stacks.
Installation, Maintenance, and Full-Cycle Support
Affixing the C-RS-402-00-0 entails aligning transducers 180° apart with magnetic straps on cleaned pipes, applying gel couplant to faces and torquing bands—its BNC cables snap into meters for 15-minute alignments via built-in setup wizards, validating paths in -40°C to 125°C flows without shutdowns.
Upkeep focuses on bi-annual couplant refreshes via peel-and-reseal, with transmitter diagnostics alerting to >10% signal fade; IP67 design endures submersion, while field-swappable pairs restore ops in 8 minutes—316SS resists scaling in brines, cutting cleanings by 40%.
GE Panametrics sustains the C-RS-402-00-0 through 24/7 cloud telemetry, mobile calibration apps, and retrofit simulations, with depot spares for next-day delivery. Spanning feasibility to fleet management, our ultrasonics team offers bespoke validations and training for perpetual flow fidelity.
