Product Description for C1CPU-4S-01 BERGHOF
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | C1CPU-4S-01 |
| Manufacturer | Berghof |
| Product Category | Controller/Module |
| Operating Voltage | 24V DC |
| Digital Inputs | 4 (configurable) |
| Digital Outputs | 4 (configurable) |
| Communication Protocol | Modbus RTU, CANopen |
| Environmental Conditions | Operating temperature: -20°C to 60°C |
| Mounting Method | DIN Rail |
| Power Consumption | 4W maximum |
| Dimensions | 90mm x 70mm x 60mm |
| Protection Class | IP20 (dustproof) |
Product Introduction
The C1CPU-4S-01 from Berghof is an advanced, compact, and reliable controller module designed for industrial automation applications. Built with versatility in mind, this controller is perfect for a wide range of control and monitoring tasks, particularly in process control, robotics, and industrial machinery.
This C1CPU-4S-01 module integrates 4 configurable digital inputs and 4 digital outputs, providing both input and output control for devices such as sensors, actuators, and switches. Its communication capabilities include support for Modbus RTU and CANopen, ensuring seamless integration with other devices and control systems.
Ideal for industrial environments, the C1CPU-4S-01 operates reliably over a wide temperature range from -20°C to 60°C, making it suitable for demanding and harsh conditions. It is designed to be mounted on a DIN rail, ensuring quick and secure installation in control cabinets or automation panels.
With its 4W maximum power consumption and compact dimensions (90mm x 70mm x 60mm), the C1CPU-4S-01 offers energy efficiency and a small form factor, making it ideal for applications with limited space and power availability.
Core Advantages and Technical Highlights
Compact and Efficient:
The C1CPU-4S-01 is designed to provide maximum functionality in a compact, space-saving design. Measuring just 90mm x 70mm x 60mm, it can be easily integrated into control panels and automation systems where space is a constraint. Despite its small size, it offers the same powerful control capabilities as larger modules.
Flexible I/O Configuration:
The C1CPU-4S-01 features 4 configurable digital inputs and 4 digital outputs, which can be easily customized to meet specific system requirements. This flexibility allows the module to handle a wide range of industrial control tasks, whether it’s monitoring sensors or controlling actuators.
Robust Communication Support:
Equipped with Modbus RTU and CANopen communication protocols, the C1CPU-4S-01 can easily integrate into various industrial networks, enabling smooth communication with other devices and controllers. These protocols ensure the module’s compatibility with both legacy and modern systems, making it a versatile solution for a wide range of industrial applications.
Reliable in Harsh Environments:
The C1CPU-4S-01 is built to operate in tough conditions, with an operating temperature range of -20°C to 60°C. It also has an IP20 protection class, ensuring that it is protected from dust and minor mechanical impact, making it reliable for use in industrial settings.
Energy-Efficient Design:
At just 4W maximum power consumption, the C1CPU-4S-01 is highly energy-efficient, reducing operational costs while maintaining high performance. This makes it a cost-effective solution for energy-conscious applications where efficiency is key.
Easy Installation:
The C1CPU-4S-01 can be mounted securely on a DIN rail, simplifying installation and reducing setup time. This mounting method ensures a stable, vibration-resistant connection, ideal for industrial environments.
Typical Application Scenarios
The C1CPU-4S-01 is a versatile controller module designed for a variety of industrial automation applications. Some typical scenarios where it is used include:
-
Process Control: In industries such as chemical, food processing, or pharmaceuticals, the C1CPU-4S-01 can be used to monitor and control process variables such as temperature, pressure, or flow rate. Its ability to integrate with various sensors and actuators makes it a reliable solution for maintaining consistency and quality in production processes.
-
Industrial Machinery Control: The C1CPU-4S-01 is ideal for controlling industrial machines, whether for managing I/O signals, controlling actuators, or interfacing with other automation systems. Its flexibility and compact size make it a suitable solution for both small and large-scale machinery control.
-
Robotics: In robotic systems, the C1CPU-4S-01 can be used for controlling sensors, motors, and feedback systems. It provides real-time communication and control, which is critical in robotic applications requiring precision and flexibility.
-
Building Automation: The C1CPU-4S-01 can also be used in building automation systems, managing HVAC systems, lighting, or security. Its communication protocols, flexibility, and low power consumption make it an ideal choice for smart building control applications.
Related Model Recommendations
-
C1CPU-8S-01: A larger version of the C1CPU-4S-01, offering 8 digital inputs and 8 digital outputs, suitable for applications requiring more I/O points.
-
C1IO-4S-01: A complementary I/O module designed to expand the I/O capabilities of the C1CPU-4S-01, providing additional input/output points.
-
C1CPU-4S-02: An upgraded version of the C1CPU-4S-01, offering enhanced communication features and additional control functionality for more complex applications.
-
C1CANopen I/O Modules: Additional I/O modules that can integrate with the C1CPU-4S-01 via CANopen communication for larger distributed systems.
-
C2PLC Series: A more powerful PLC series from Berghof that can complement the C1CPU-4S-01 in applications requiring more advanced control features.
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Before installing the C1CPU-4S-01, ensure that the surrounding environment is within the recommended temperature range of -20°C to 60°C. Mount the module securely on a DIN rail inside the control panel, ensuring there is adequate ventilation and space for cable connections. Double-check all electrical wiring, including the power supply and I/O connections, to ensure proper operation.
Maintenance Suggestions:
The C1CPU-4S-01 is designed for minimal maintenance due to its robust construction. However, periodic inspection is recommended to ensure there is no dust buildup, especially on the terminals and connectors. Ensure that the module is functioning properly by checking its communication with connected devices and ensuring I/O operations are as expected. For any persistent issues, consult Berghof’s technical support for diagnostics and troubleshooting.
Service and Guarantee Commitment
Berghof offers a standard warranty for the C1CPU-4S-01, covering defects in materials and workmanship. Their commitment to product quality is demonstrated through ongoing support services, including troubleshooting, system integration assistance, and performance optimization. Should any issues arise, Berghof’s technical support team is available to assist with problem resolution, ensuring the longevity and reliability of the C1CPU-4S-01 in industrial applications.
