Product Description for C1CPU-4S-07 BERGHOF
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | C1CPU-4S-07 |
| Manufacturer | Berghof |
| Product Category | Controller/Module |
| Operating Voltage | 24V DC |
| Digital Inputs | 4 (configurable) |
| Digital Outputs | 4 (configurable) |
| Communication Protocol | Modbus RTU, CANopen |
| Environmental Conditions | Operating temperature: -20°C to 60°C |
| Mounting Method | DIN Rail |
| Power Consumption | 4W maximum |
| Dimensions | 90mm x 70mm x 60mm |
| Protection Class | IP20 (dustproof) |
Product Introduction
The C1CPU-4S-07 from Berghof is a compact, reliable, and flexible automation controller designed for industrial control systems. As part of Berghof’s C1 series, the C1CPU-4S-07 provides an ideal solution for managing digital inputs and outputs in applications where space, power efficiency, and flexibility are essential.
Equipped with 4 configurable digital inputs and 4 configurable digital outputs, the C1CPU-4S-07 is capable of controlling a wide variety of devices such as sensors, actuators, and switches. The module features Modbus RTU and CANopen communication protocols, enabling seamless integration into a range of industrial networks. This allows the C1CPU-4S-07 to communicate with other devices and systems efficiently, providing real-time control and monitoring.
With an operating temperature range of -20°C to 60°C, the C1CPU-4S-07 is built to operate reliably in both harsh and standard industrial environments. It is designed for easy mounting on a DIN rail, ensuring quick and secure installation, even in space-constrained control panels.
The C1CPU-4S-07 is energy-efficient, consuming a maximum of just 4W, and its IP20 protection class ensures reliable operation in industrial settings, offering protection from dust and minor mechanical impact.
Core Advantages and Technical Highlights
Compact and Energy-Efficient:
The C1CPU-4S-07 provides outstanding control in a compact form factor. With dimensions of 90mm x 70mm x 60mm, it’s ideally suited for control systems with limited space. Despite its size, it offers full functionality with 4 digital inputs and 4 digital outputs. Its 4W maximum power consumption ensures that it operates efficiently, reducing the overall energy footprint of the automation system.
Flexible I/O Configuration:
The module offers 4 digital inputs and 4 digital outputs, all of which are configurable to suit the specific needs of various industrial automation tasks. This flexibility allows the C1CPU-4S-07 to control and monitor a wide variety of devices, such as sensors, actuators, and relays, adapting to different types of systems and processes.
Robust Communication Support:
The C1CPU-4S-07 supports both Modbus RTU and CANopen communication protocols, making it versatile for different types of industrial networks. These widely adopted protocols ensure that the module can easily integrate with a variety of other control devices, systems, and controllers, enabling efficient communication and control.
Reliable Operation in Harsh Environments:
Operating in temperatures from -20°C to 60°C, the C1CPU-4S-07 can be deployed in challenging environments, such as factories or outdoor installations, where temperature fluctuations or dust exposure might occur. Its IP20 protection class ensures it is protected from dust and minor mechanical impact, enhancing its durability.
Easy Installation and Maintenance:
The C1CPU-4S-07 is designed for easy installation, mounting securely on a DIN rail. This simplifies integration into control panels, reduces installation time, and ensures a stable connection. Its low power consumption and minimal maintenance requirements further enhance the ease of use and operational cost-effectiveness.
Typical Application Scenarios
The C1CPU-4S-07 is designed for use in a wide range of industrial applications that require efficient and reliable control over I/O operations. Some typical application scenarios include:
-
Manufacturing Automation: The C1CPU-4S-07 is ideal for controlling and monitoring machinery, sensors, and actuators in production lines. It can handle tasks such as controlling motors, monitoring temperature sensors, or managing other I/O devices, contributing to enhanced efficiency and reduced downtime.
-
Process Control: In industries such as chemicals, food processing, and pharmaceuticals, the C1CPU-4S-07 can manage process variables like pressure, temperature, and flow. It enables real-time data communication and control, ensuring stable and efficient processes.
-
Building Automation: The C1CPU-4S-07 can be employed in HVAC systems, lighting control, and security monitoring within buildings. With its communication protocols and I/O capabilities, it can integrate into smart building systems to optimize energy consumption and enhance system reliability.
-
Robotics and Mechatronics: The module’s flexibility makes it a good choice for controlling sensors, actuators, and feedback systems in robotics or other automated machinery, where precise control and real-time feedback are essential.
Related Model Recommendations
-
C1CPU-8S-07: A variant with 8 digital inputs and 8 digital outputs, suitable for applications requiring a larger number of I/O points.
-
C1CANopen I/O Modules: Additional I/O expansion modules that integrate with the C1CPU-4S-07 to provide more input/output points for larger systems.
-
C1CPU-4S-08: A version that offers enhanced communication support with additional protocol options for more advanced networking needs.
-
C2PLC Series: For more complex control and automation tasks, Berghof’s C2PLC series can work seamlessly with the C1CPU-4S-07, offering higher processing power and greater scalability.
-
C1IO-4S-01: An I/O expansion module designed for applications requiring more I/O points to expand the capabilities of the C1CPU-4S-07.
Installation, Commissioning and Maintenance Instructions
Installation Preparation:
Before installation, verify that the operating environment of the C1CPU-4S-07 meets the temperature range of -20°C to 60°C. Mount the controller securely onto a DIN rail inside the control panel, ensuring adequate ventilation and accessibility for wiring. Double-check all wiring connections, especially the power supply and I/O connections, to avoid errors during operation.
Maintenance Suggestions:
The C1CPU-4S-07 is designed to operate with minimal maintenance. However, regular checks are recommended to ensure reliable operation. Inspect the module for signs of physical damage, dust buildup, or loose connections. Keep the area around the module clean to ensure proper airflow. If issues occur, such as communication errors or I/O failures, refer to Berghof’s diagnostic tools or contact their technical support team for troubleshooting.
Service and Guarantee Commitment
Berghof offers a standard warranty for the C1CPU-4S-07, which covers any defects in material and workmanship. In addition, Berghof provides comprehensive technical support services to assist with installation, troubleshooting, and system optimization. With a commitment to product quality and customer satisfaction, Berghof ensures that the C1CPU-4S-07 will operate reliably throughout its lifecycle, backed by expert customer service and support.
