Product introduction
The ABB Advance Optima AO2040 MAGNOS28 is a sophisticated, modular industrial process gas analyzer system that integrates a high-performance MAGNOS28 paramagnetic oxygen analyzer into the robust Advance Optima AO2040 platform. This integrated solution is meticulously engineered for continuous and precise measurement of oxygen concentration, which is a critical parameter in numerous industrial processes. As a key component of the ABB Advance Optima family, the ABB Advance Optima AO2040 MAGNOS28 is an essential tool for ensuring process efficiency, product quality, and safety.
The heart of this system, the MAGNOS28 module, utilizes the paramagnetic principle, which is based on the fact that oxygen is a highly paramagnetic gas. A sample gas stream is introduced into a sensor, where a magnetic field measures the paramagnetic properties of the oxygen molecules. This technology provides highly selective and stable measurements with minimal cross-interference from other gases. The modular design of the ABB Advance Optima AO2040 MAGNOS28 platform ensures that the system can be easily expanded or upgraded with other analyzer modules to create a comprehensive, multi-component analytical solution.
Core advantages and technical highlights
The ABB Advance Optima AO2040 MAGNOS28 offers a significant advantage in industrial gas analysis due to its highly selective and reliable measurement technology. The paramagnetic principle of the MAGNOS28 module is renowned for its accuracy and stability, making it an excellent choice for measuring oxygen in a variety of background gases. This is a crucial feature for applications where the oxygen concentration is critical, such as in combustion control to ensure optimal efficiency and safety. The system’s innovative design also features a robust sensor that provides a long service life and requires minimal maintenance, significantly reducing the total cost of ownership. The ABB Advance Optima AO2040 MAGNOS28 is built for continuous operation in demanding environments.
Another key highlight is the system’s modularity and automation. The ABB Advance Optima AO2040 MAGNOS28 can house up to four different analyzer modules, which allows for multi-component analysis within a single, compact unit. This reduces the need for multiple separate systems, simplifying installation and maintenance. The system’s automatic calibration feature and self-diagnostic capabilities are also a major benefit, providing proactive alerts for potential issues and ensuring continuous uptime. Furthermore, the ABB Advance Optima AO2040 MAGNOS28 is designed to comply with hazardous area approvals, confirming its suitability for deployment in safety-critical applications.
Typical application scenarios
The ABB Advance Optima AO2040 MAGNOS28 is indispensable in several key industries where precise oxygen analysis is critical. A primary application is in combustion control in power plants, boilers, and industrial furnaces. By measuring the oxygen content in flue gas, the system helps optimize the air-fuel ratio, leading to improved energy efficiency and reduced emissions. In the chemical and petrochemical industries, the ABB Advance Optima AO2040 MAGNOS28 is used for safety monitoring and purity analysis, such as ensuring the correct oxygen concentration in process gas streams to prevent explosions or to monitor nitrogen blanketing systems.
The system is also vital in the production of inert gases, where it is used to monitor oxygen purity. The ABB Advance Optima AO2040 MAGNOS28‘s ability to handle multiple analyzer modules in a single platform makes it suitable for complex applications. For instance, it can be combined with an NDIR analyzer to simultaneously measure carbon monoxide and oxygen, providing comprehensive data for combustion optimization. Its robust design and compliance with hazardous area approvals make the ABB Advance Optima AO2040 MAGNOS28 suitable for installation in harsh and potentially explosive atmospheres. In all these applications, the data provided by the ABB Advance Optima AO2040 MAGNOS28 is invaluable for improving plant efficiency, ensuring product quality, and maintaining compliance with environmental and safety standards.
Related model recommendations
The ABB Advance Optima AO2040 MAGNOS28 is a part of a modular family of analyzers. Other related models and components include:
Advance Optima AO2020: A smaller, single-module analyzer from the same series, ideal for applications that only require one measurement technology.
URAS26: An NDIR photometer analyzer module that can be integrated into the ABB Advance Optima AO2040 system to measure infrared-active gases like CO₂ and CO, often in parallel with the MAGNOS28.
CALDOS27: A thermal conductivity analyzer module that can be integrated into the ABB Advance Optima AO2040 for measuring gases like hydrogen or helium, often used as a complementary measurement to the MAGNOS28.
LIMAS21: A UV-Vis photometer module that can be integrated into the ABB Advance Optima AO2040 for measuring gases like SO₂ and NOx.
Magnos 28: The standalone paramagnetic oxygen analyzer module itself, which highlights the modularity of ABB’s offerings.
