AO2040-URAS14 ABB
AO2040-URAS14 ABB - Image 2
AO2040-URAS14 ABB - Image 3

AO2040-URAS14 ABB

Installation, commissioning and maintenance instructions

Installation preparation: Before installing the ABB Advance Optima AO2040 URAS14, it’s crucial to select an appropriate location that is free from excessive vibration, dust, and direct sunlight. The 19″ chassis is designed for rack mounting, so ensure the rack is secure. Proper power supply connection and grounding are essential for safe and stable operation. All sample and vent gas lines must be correctly connected and checked for leaks to ensure the integrity of the measurement. It is recommended to follow the detailed instructions in the product manual to ensure all steps are performed correctly for the ABB Advance Optima AO2040 URAS14.

Maintenance suggestions: The ABB Advance Optima AO2040 URAS14 is engineered for minimal maintenance. Routine tasks primarily involve checking and replacing filters in the sample conditioning system and ensuring the sample flow is within specified limits. The system’s self-diagnostic features will alert you to any issues with the URAS14 photometer itself. In the event of a fault, the modular design allows for a quick and easy replacement of the URAS14 module, minimizing system downtime. Periodic calibration checks with certified test gases, while reduced by the automatic calibration feature, are still recommended to ensure long-term measurement accuracy.

Service and guarantee commitment

We are committed to providing comprehensive support for the ABB Advance Optima AO2040 URAS14. Our quality assurance program ensures that every unit is built to the highest industrial standards for performance and reliability. We offer a robust warranty and provide exceptional after-sales support through a global network of expert technicians. Our goal is to be a long-term partner, offering technical assistance, readily available spare parts, and on-site service to ensure your ABB Advance Optima AO2040 URAS14 system operates at peak performance for years to come.

Add to Quote
Category:
  • Email:sales@sxrunsheng.cn
  • Phone:+86 15340667322
  • Whatsapp：+86 15340667322

    • Description

    Detailed parameter table

    Parameter Name Parameter Value
    Product model Advance Optima AO2040 URAS14
    Manufacturer ABB
    Product category Industrial Process Gas Analyzer System with NDIR Photometer
    Measurement Technology Non-Dispersive Infrared (NDIR)
    Measurement Principle Infrared-active gases, such as CO and
    Typical Applications CEMS, combustion control, purity monitoring
    System Configuration 19″ chassis with integrated URAS14 module
    Communication Interface Ethernet TCP/IP, PROFIBUS, Modbus, OPC
    Hazardous Area Approval ATEX and GOST-R, 2G, 3G, CSA Class I, Division 2
    Enclosure Protection Varies based on model and hazardous area classification
    System Dimensions 483 mm (W) x 177 mm (H) x 412 (597) mm (D)
    Maximum Modules Up to 4 analyzer modules

    Product introduction

    The ABB Advance Optima AO2040 URAS14 is a state-of-the-art industrial process gas analyzer system built on a foundation of precision and reliability. As a core component of the ABB Advance Optima family, the ABB Advance Optima AO2040 URAS14 utilizes the proven URAS14 photometer module. This module employs Non-Dispersive Infrared (NDIR) technology, which is ideal for selectively measuring gases that absorb infrared radiation. The integration of this module within the robust 19-inch chassis of the ABB Advance Optima AO2040 ensures a compact, yet powerful, analytical solution. The modular design of the AO2040 platform ensures that this system can be easily expanded or upgraded with other analyzer types, such as oxygen or thermal conductivity analyzers, to meet future needs.

    Core advantages and technical highlights

    The ABB Advance Optima AO2040 URAS14 stands out in the industrial gas analysis market due to its technical excellence and functional superiority. A primary advantage of the URAS14 module is its robust and reliable NDIR measurement principle. The system provides long-term stability and minimizes the influence of background gases, ensuring reliable measurements with very low drift. This leads to a significant reduction in the frequency of calibration and maintenance, lowering the total cost of ownership. The system’s self-diagnostic function provides real-time status updates and proactively alerts operators to potential issues, allowing for predictive maintenance rather than reactive repairs. The robust communication interfaces, including PROFIBUS and Modbus, allow the ABB Advance Optima AO2040 URAS14 to seamlessly integrate into any modern DCS or PLC system, providing plant-wide access to critical analytical data for enhanced process control and decision-making.

    Typical application scenarios

    The ABB Advance Optima AO2040 URAS14 is a cornerstone of process and environmental monitoring in numerous industries. In the power generation and cement industries, it is a critical component of Continuous Emissions Monitoring Systems (CEMS), measuring flue gases to ensure compliance with environmental regulations for pollutants like and . In the chemical and petrochemical industries, the ABB Advance Optima AO2040 URAS14 is deployed to monitor gas purity and manage process safety. It can be used to analyze the concentration of or in synthesis gas or other reactor inputs to ensure the correct stoichiometry for efficient chemical reactions. The system’s reliable performance and ability to operate in challenging conditions make it suitable for installation in remote or hazardous areas.

    AO2040-URAS14 ABB

    Related model recommendations

    The ABB Advance Optima AO2040 URAS14 is part of a family of modular analyzers. Other related models and components include:

    Advance Optima AO2040 Magnos206: A paramagnetic oxygen analyzer module that often works in tandem with the URAS14 for combustion control and safety applications.

    Advance Optima AO2040 CALDOS27: This system integrates a thermal conductivity analyzer, used for measuring gases like hydrogen or helium, which can be a complementary measurement to the URAS14.

    Advance Optima AO2040 LIMAS21: A UV-Vis photometer module that can be integrated into the ABB Advance Optima AO2040 for measuring gases like and .

    Advance Optima AO2020: A smaller, single-module analyzer from the same series, ideal for applications that only require one measurement technology.
