Description
Detailed Parameter Table
| Parameter Name | Parameter Value |
|---|---|
| Product Model | DASD‑CT15SPXB |
| Manufacturer | Daewoo Heavy Industries |
| Product Category | AC Servo Drive (1.5 kW Class) |
| Rated Output Power | 1.5 kW |
| Input Voltage | 3-Phase 200–230 V AC, 50/60 Hz |
| Rated Output Current | 10.3 A (continuous) |
| Maximum Output Current | 31 A (peak) |
| Control Method | Speed and Position Control (Absolute Encoder) |
| Communication Interface | Standard digital/analog I/O, pulse train, encoder |
| Operating Temperature Range | 0 °C – +40 °C |
| Mounting Type | Panel or rack-mounted module |
| Protection Features | Overcurrent, overheat, over-voltage, encoder loss |
Product Introduction
The Daewoo DASD‑CT15SPXB is an advanced AC servo drive in the 1.5 kW class, designed to deliver precise speed and position control for industrial automation applications. As part of Daewoo’s CT series, the DASD‑CT15SPXB integrates high-performance motion control algorithms with absolute encoder feedback, ensuring accurate, repeatable positioning and smooth dynamic response.
The DASD‑CT15SPXB serves as a core component in CNC machines, robotic systems, and automated production lines, acting as the power amplifier and control interface between the servo motor and the system controller. Its robust design allows it to operate reliably under industrial conditions, including fluctuating temperatures, vibration, and continuous duty cycles.
Thanks to its modular design and standardized I/O, the DASD‑CT15SPXB is easily integrated into existing systems or used as a replacement or upgrade for older CT series drives. Its combination of compact size, precise control, and industrial durability makes it a versatile choice for OEMs, integrators, and maintenance engineers seeking reliable and service-friendly motion control solutions.
Core Advantages and Technical Highlights
Precision motion control:
With absolute encoder support and advanced speed/position loops, the DASD‑CT15SPXB provides highly accurate motion with minimal positioning error, ensuring smooth operation for high-precision machinery.
Industrial durability:
Engineered for harsh factory environments, the DASD‑CT15SPXB features protection against overcurrent, over-voltage, and thermal overloads. Its high-quality components and robust casing guarantee long-term reliability.
Flexible integration:
The drive supports standard digital and analog inputs, encoder feedback, and pulse commands, allowing seamless integration with PLCs, motion controllers, or standalone automation systems. This versatility simplifies commissioning and configuration.
Maintenance efficiency:
The modular design of the DASD‑CT15SPXB allows quick replacement or upgrade without complex rewiring. Diagnostic LEDs and standardized parameters assist maintenance staff in troubleshooting and system optimization.
Optimized performance and energy efficiency:
The drive’s control algorithms provide smooth acceleration and deceleration, reduce mechanical stress, and improve energy efficiency, enhancing overall system productivity while maintaining motor longevity.
