Sale!
ABB PP885M (3BSE069280R1) | Genuine New Original Marine HMI
ABB PP885M (3BSE069280R1) | Genuine New Original Marine HMI - Image 2
ABB PP885M (3BSE069280R1) | Genuine New Original Marine HMI - Image 3

ABB PP885M (3BSE069280R1) | Genuine New Original Marine HMI

Original price was: $8,797.00.Current price is: $3,546.00.

Product Core Brief

  • Model: PP885M
  • Brand: ABB
  • Series: Panel 800 (Marine/Rugged)
  • Core Function: Marine-grade operator interface engineered for bridge and engine room visualization in high-vibration environments.
  • Type: Ruggedized Touchscreen HMI
  • Key Specs: 15.1″ TFT-LCD, 1024 x 768 XGA resolution, 1.0 GHz ARM Cortex-A8.
  • Condition: New Original (New Surplus), not refurbished
  • ⚠️ Discontinued; limited stock
Add to Quote
Category: SKU: PP885M 3BSE069280R1 ABB
  • Email:sales@sxrunsheng.cn
  • Phone:+86 15340667322
  • Whatsapp：+86 15340667322

    • Description

    Product Introduction

    In maritime propulsion and ballast control, the ABB PP885M (3BSE069280R1) serves as a critical visualization node designed to meet the rigorous vibration and salt-mist requirements of bridge-mounted equipment. Unlike standard industrial panels, the “M” designation indicates specialized marine hardware, featuring a dimmable backlight that can be reduced to 0% for night-watch navigation.

    Selecting the ABB PP885M (3BSE069280R1) provides the high-performance ARM Cortex-A8 architecture needed to run the Panel Builder 600 runtime smoothly. This 15.1-inch model is often the preferred replacement for aging maritime displays where high-resolution XGA graphics and multi-protocol connectivity (Modbus, Profibus, etc.) are required for integrated vessel management.



    Key Selling Points & Differentiators

    • Marine Certification: Fully certified by major maritime societies (DNV, ABS, Lloyd’s Register), ensuring compliance with offshore safety and electromagnetic interference standards.
    • Low-Light Capability: Features a dimmable backlight optimized for bridge operation, preventing operator glare during night-time maneuvers.
    • Hardware Robustness: Compared to the standard PP885, the ABB PP885M (3BSE069280R1) features reinforced internal components to withstand constant hull vibration and thermal cycling.
    • Installation Limit: Not recommended for direct outdoor deck mounting without an additional protective enclosure; while IP66-rated at the front, UV exposure will eventually degrade the touch overlay.
    • Quality Verification: Every unit undergoes a 500 V insulation test and a 24-hour heat-soak at 50°C to ensure field reliability before shipping.



    Quality Transparency Strategy

    To ensure the reliability of this discontinued spare, we follow a strict engineering inspection for every ABB PP885M (3BSE069280R1):

    1. Incoming Inspection: We verify the factory seal and perform a microscopic inspection of the front gasket to ensure it hasn’t become brittle during storage.
    2. Live Functional Test: The unit is powered on a 24 V DC test bench to verify boot behavior, touch linearity, and color accuracy across the full 15.1-inch display.
    3. Marine-Specific Check: We specifically verify the backlight dimming range from 100% down to 0% to ensure the unit meets bridge-operability standards.
    4. Communication Integrity: Both Ethernet ports and the serial terminal are tested for data packet stability using a Modbus TCP handshake.
    5. Final QC: The ABB PP885M (3BSE069280R1) is sealed in a moisture-barrier ESD bag and packed with triple-wall corrugated protection for international air freight.



    “Old-Hand” Technical Pitfall Guide

    1. Firmware Version Compatibility: Ensure your existing project was built in a version of Panel Builder 600 compatible with the firmware on the ABB PP885M (3BSE069280R1). If you are replacing a V1 panel with a V2, a project upgrade is mandatory.
    2. ❗ Grounding on Vessels: In marine environments, proper grounding is non-negotiable. Ensure the functional earth (FE) terminal is connected to a clean ship’s ground to prevent “ghosting” on the touchscreen caused by EMI from nearby radar or radio equipment.
    3. Backlight Life Management: While the LED is rated for 50,000 hours, running at 100% brightness in high-temperature engine rooms will shorten its life. Use the software’s “auto-dim” feature when the panel is idle.
    4. Serial Port Pinouts: ABB’s RS422/485 pinout on the ABB PP885M (3BSE069280R1) may differ from generic marine electronics. Always check the wiring diagram in the 3BSE069280R1 manual; don’t wire by memory.
    5. Static Handling: I’ve seen communication chips on these panels fail due to static discharge when a technician plugged in a laptop without first grounding the chassis. Use an ESD strap during any cabling work.

    ABB PP885M (3BSE069280R1) | Genuine New Original Marine HMI
