Description
Key Technical Specifications
- Display Size: 15 in TFT LCD
- Resolution: 1024 × 768 pixels
- Touch Type: Analog resistive touchscreen
- Supply Voltage: 24 V DC (19.2–30 V DC range)
- Power Consumption: ~24 W typical
- Communication Ports: Ethernet RJ45 | RS-232 | RS-485
- USB Ports: 2 × USB host
- Operating Temperature: 0 to 50 °C
- Storage Temperature: -20 to 60 °C
- Mounting: Panel mount (cutout per ABB spec)
- Protection Rating: Front IP66 / NEMA 4X (when properly installed)
- Programming Software: Panel Builder 800 (IEC 61131 integration via controller)
Product Introduction
ABB PP865A is a 15-inch operator panel from the Panel 800 series, designed for industrial HMI applications in process and discrete automation. It provides real-time visualization, alarm handling, and operator interaction for PLC and DCS systems across manufacturing and utilities.
This unit supports Ethernet and serial protocols, including Modbus TCP and Modbus RTU, enabling integration with mixed-vendor environments. It is commonly deployed with ABB AC800M controllers, reducing engineering overhead through standardized tools like Panel Builder 800.
