Description
Key Technical Specifications
- Supply Voltage: 24 V DC nominal (19.2 – 30 V permissible)
- Housing: RECO02 carrier, occupies two slots
- Interfaces: SERCOS (fiber optic typical) | Serial ports
- Expansion: Up to three slots depending on exact variant configuration
- Memory: PCMCIA flash card slot
- Protection Rating: IP20
- Weight: Approx. 1.3 kg
- Mounting: Module carrier in control cabinet
- Temperature Range: 0 °C to +55 °C (verify exact in datasheet)
- Communication: Supports Profibus, DeviceNet or other fieldbus via optional modules
- Application: Multi-axis servo control with integrated PLC
Product Introduction Rexroth PPC-R02-2N.N-Q1-P2 is a RECO02 format motion controller from Bosch Rexroth. It provides combined motion control and logic functions for multi-axis servo systems in packaging, printing, and machine tool applications.
This unit supports SERCOS communication to drives and multiple expansion options for fieldbus connectivity. It delivers reliable performance in existing VisualMotion or IndraMotion installations while helping maintain spare parts compatibility across the platform.
